C175

Highest torque-to-weight ratio in its class.

A high-torque, low-weight professional-grade mulching tractor, designed for superior maneuverability on tight, difficult terrain.

Operating Weight: 17 621 lb (7 992 kg)
Hydraulic Flow: Variable speed from 0 to 3.98 mph (0 to 6.4 km/h)
Engine Power: 175 HP class

Power where it counts. Control when it matters.

The C175 is a purpose-built mulching tractor designed for operators who need serious torque in a compact machine. Its combination of traction, ground clearance, and continuous-duty capability allows it to perform reliably through dense vegetation, uneven ground, and soft terrain. A standard 15,000-lb winch provides self-recovery capability in challenging conditions. Built on a smaller crawler platform, the C175 is easy to transport between job sites, while its straightforward design prioritizes control, durability, and uptime.

KEY BENEFITS

Highest torque in its class
Strong traction and stability on uneven ground
Low ground impact in sensitive or soft ground
Simplified maintenance for reduced downtime

Fits tight corridors. Tackles tough terrain.

The C175 is engineered to deliver high torque and reliable traction in a compact, purpose-built platform. Its clear-through bottom design, high ground clearance, and robust undercarriage design allow it to perform consistently in demanding ground conditions and uneven surfaces. Mechanical simplicity and field-tested components support controlled, dependable mulching performance with extended runtime between refueling.

Specifications

MANUFACTURER & MODEL: CUMMINS B4.5 Stage V
CYLINDERS & DISPLACEMENT: 4 cylinders / 19 Gal US (110 L)
PEAK POWER AT 1800 RPM (SAE J1995): 173 hp (129 kW)
NET PEAK TORQUE: 575 ft·lbf (780 Nm)
FAN: Automatic variable pitch, reversible

FILTRATION: 10 Microns
PUMP SYSTEM: 4

VOLTAGE: 12 Volts
STANDARD LIGHT: 8 LED type (4 Front, 2 Side, 2 Rear)

Motor: Two speed hydraulic motors
Speed: Variable speed from 0 to 3.98 mph (0 to 6.4 km/h)

FUEL TANK: 66.6 gal US (252 L)
HYDRAULIC RESERVOIR: 4 cylinders / 275 CID (4.5 L)
COOLING SYSTEM: 17.13 gal US (27 L)

CHAIN TYPE & SIZE: Seal and lube track (SALT) D3
TRACK SHOE & ROLLERS: 22 in (560 mm) single grouser with mud hole, dozer type rollers. 30 in (760 mm) pads optional
GROUND PRESSURE (22-IN PADS): 3.88 psi (0.27 kg/cm²)
GROUND PRESSURE (30-IN PADS): 2.94 psi (0.21 kg/cm²)

LENGTH: 173 in (439 cm)
GROUND CLEARANCE: 22 in (56 cm)
OVERALL HEIGHT: 111 in (281 cm)
WIDTH (22-IN PADS): 81 in (207 cm)
WIDTH (30-IN PADS): 89 in (227 cm)
WEIGHT (22-IN PADS): 17 621 lb (7 992 kg)
WEIGHT (30-IN PADS): 18 213 lb (8 261 kg)
