C400

A high-drive system for high-speed clearing.

Built for sustained production, the C400 combines high-drive clearance, torque, and stability for large-scale clearing operations.

Operating Weight: 31,950 lb (14,492 kg)
Hydraulic Flow: To review
Engine Power: 400 HP Class

Industry-leading clearance keeps the machine moving.

Conventional undercarriages are vulnerable to debris buildup. The C400L isn’t. With 22 inches of ground clearance, critical moving parts stay above the debris line, protected from buildup and contamination. The result is sustained speed and continuous operation in harsh conditions—a high-drive design proven for decades in demanding pipeline work.

KEY BENEFITS

Sustained high-speed clearing performance
Debris-free operation for continuous clearing
Reduced maintenance stops on large-scale jobs
Proven track frame built for pipeline and forestry work

Engineered for large-scale operations.

At the core of the C400 is a Cummins L9 engine that delivers 1,324 lb-ft of torque. That power is supported by CMI’s proven dozer-design track frame and a D4 sealed and greased undercarriage built for demanding, continuous work. An efficient hydraulic system channels engine output into steady, controlled mulching performance—maintaining torque under load and consistent cutting power through dense vegetation, heavy material, and large-scale clearing applications.

Specifications

MANUFACTURER & MODEL: CUMMINS L9 Stage V
CYLINDERS & DISPLACEMENT: 6 cylinders / 543 CID (8.9 L)
PEAK POWER AT 1800 RPM (SAE J1995): 400 hp (298 kW)
NET PEAK TORQUE: 1,324 ft-lbf (1,795 Nm)
FAN: Automatic variable pitch, reversible

FILTRATION: 10 Microns
PUMP SYSTEM: 4

VOLTAGE: 12 Volts
STANDARD LIGHT: 8 LED type (4 Front, 2 Side, 2 Rear)

Motor: Two speed hydraulic motors
Speed: Variable speed from 0 to 4.0 mph (0 to 6.5 km/h)

FUEL TANK: 134.5 gal US (509 L)
HYDRAULIC RESERVOIR: 76 gal US (288 L)
COOLING SYSTEM: 10.6 gal US (40 L)

CHAIN TYPE & SIZE: Sealed and greased, D4 with an elevated final drive design
TRACK SHOE & ROLLERS: Standard 24 in (610 mm) single grouser with mud hole
GROUND PRESSURE (24-IN PADS): 5.15 psi (0.36 kg/cm2)
GROUND PRESSURE (30-IN PADS): 4.22 psi (0.30 kg/cm2)

OVERALL LENGTH: 206 in (523 cm)
GROUND CLEARANCE: 25 in (63 cm)
OVERALL HEIGHT: 129.3 in (328 cm)
WIDTH (24-IN PADS): 92.1 in (234 cm)
WIDTH (30-IN PADS): 98.1 in (249 cm)
WEIGHT (24-IN PADS): 31 950 lb (14 492 kg)
WEIGHT (30-IN PADS): 32 750 lb (14 855 kg)
